Android Player
Operation system : Android 11
CPU : Quad-core ARM®Cortex-A53 up to 2.0GHz
GPU : IMG Ge8300
RAM : 2GB, DDR4
ROM : 32GB
DSP : AKM7604 | 13 bands
HIFI : 4 x 50 PMPO
BT : Bluetooth version is 5.0 choose and shift freely between internal and external microphone.
GNSS : GPS/GLONASS/BeiDou/Galileo/QZSS
WIFI : Dual-band (2.4 & 5GHz) 802.11 c/a/b/g/n | 20/40/80MHz bandwidth
Radio : Built-in FM
Amplifier IC : TCB001 for 2+32G
RCA output : 4V
Touch panel : Capacitive
Resolution : 1280x720 for 9" and 10"
USB : 2*USB
Steering wheel control support : Yes
Mirror link : CarPlay and Android Auto
Working voltage : 9V~ 16V
Rear camera : Compatible with normal resolution and 720P and 1080P AHD camera
Front camera : Only support 720P AHD camera
DVR : Support
Working temperature : -20°C~70°C
Storage temperature : -30°C~80°C
360° camera support : Yes
Ports : 2-way USB 2.0 high speed ports; Camera ports CVBXx1 and | AHDx4;6-way Line-out output @4Vrms; UARTx2 port, GPS ports, car ports:ILL/ Reverse/ACC/SWC/Radio
Android Player
Operation system : Android 11
CPU : Octa core
GPU : IMG Ge8300
RAM : 4GB, DDR4
ROM : 32GB
DSP : AKM7604 | 13 bands
HIFI : 4 x 50 PMPO
BT : Bluetooth version is 5.0 choose and shift freely between internal and external microphone.
GNSS : GPS/GLONASS/BeiDou/Galileo/QZSS
WIFI : Dual-band (2.4 & 5GHz) 802.11 c/a/b/g/n | 20/40/80MHz bandwidth
Radio : Built-in FM
Amplifier IC : TCB001 for 4+32G
RCA output : 4V
Touch panel : Capacitive
Resolution : 1280x720 for 9" and 10"
USB : 2*USB
Steering wheel control support : Yes
Mirror link : CarPlay and Android Auto
Rear camera : Compatible with normal resolution and 720P and 1080P AHD camera
Front camera : Only support 720P AHD camera
DVR : Support
Working voltage : 9V~ 16V
Working temperature : -20°C~70°C
Storage temperature : -30°C~80°C
360° camera support : Yes
Ports : 2-way USB 2.0 high speed ports; Camera ports CVBXx1 and | AHDx4;6-way Line-out output @4Vrms; UARTx2 port, GPS ports, car ports : ILL/ Reverse/ACC/SWC/Radio
Android Player
Operation system : Android 11
CPU : Octa core
GPU : IMG Ge8300
RAM : 6GB, DDR4
ROM : 128GB
DSP : AKM7604 | 13 bands
HIFI : 4 x 50 PMPO
BT : Bluetooth version is 5.0 choose and shift freely between internal and external microphone.
GNSS : GPS/GLONASS/BeiDou/Galileo/QZSS
WIFI : Dual-band (2.4 & 5GHz) 802.11 c/a/b/g/n | 20/40/80MHz bandwidth
Radio : Built-in FM
Amplifier IC : TCB001 for 6+128GB
RCA output : 4V
Touch panel : Capacitive
Resolution : 1280x720 for 9" and 10"
USB : 2*USB
Steering wheel control : Support
Mirror link : CarPlay and Android Auto
4G : Yes
Rear camera : Compatible with normal resolution and 720P and 1080P AHD camera
Front camera : Only support 720P AHD camera
DVR : Support
Working voltage : 9V~ 16V
Working temperature : -20°C~70°C
Storage temperature : -30°C~80°C
360° camera support : Yes
Ports : 2-way USB 2.0 high speed ports; Camera ports CVBXx1 and | AHDx4;6-way Line-out output @4Vrms; UARTx2 port, GPS ports, car ports:ILL/ Reverse/ACC/SWC/Radio
